10 | M-5 Instruction Guide
Technical specifications
Frequency band* 26.565-27.99125 MHz
Dimensions 110 x 120 x 25 mm
Weight 380gr
Supply voltage 12.6V ± 10%
Current consumption 2 A max
Operating temperature -10 to +55 °C
Antenna socket UHF, SO-239
Frequency error < +/- 300 Hz
TX power 4 Watt
Duty cycle (% on 1 hour) TX 5% / RX 5% / Stand-by 90%
Spurious emissions < 4 nW (-54 dBm)
Adjacent channel power < 20 μW
FM deviation 1,9 kHz
AM modulation index 85-90%
RX sensitivity better than 1 μV
Image rejection 70 dB
Adjacent channel rejection 60 dB
Dual audio output 3 Watt (8 Ohm) radio body; 2 Watt (16 Ohm) microphone
Frequency response 300-3000 Hz
*covering all approved EU frequency bands.
Specifications are subject to change without notice.
A redily accessibile disconnect device shell be incorporated in the installation wiring. The di-
sconnect device shall disconnect both poles simultaneously.
