STEP 3
Now place the threads of the motor into a 9/16”
collet (far left picture). Remove the motor
housing by unthreading it in a counterclockwise
direction. Place the outer housing on your work
surface and then remove the motor canister
from the base piece (near left picture). It should
simply lift out with little resistance.
STEP 4
Take time to note that the motor canister sits
correctly in the base piece by aligning posts.
The two male posts in the base piece line up
with the two female holes in the canister. At
left, you can see the two meshing pieces.
