STEP 3
To remove the small brass clip washer, take your exacto knife
and carefully slip it out of its groove. Then, slowly slide it up
and off the end of the chuck.
STEP 4
Once the brass clip washer has been removed,
you can slide the 60102 spindle bearing up
and off of the chuck as well. If the chuck is
broken, simply tap out the small 60219A pin
holding the chuck and drive fork together.
