The machine door hinges are adjustable in order
to align the door with the surrounding cabinets
To adjust the door in direction b, turn screw b.
To adjust the height of the door (direction c), turn
screw
c.
To adjust the door forwards or backwards, (direc-
tion
d), turn screw d.
Installation
67
