Installation
27
Attach the vapour canopy with
cabinet door fitted and then close it.
It is possible to adjust the movement
of the vapour canopy. This may be
required if a heavy cabinet door is to
be fitted, for example.
Remove the two cover caps which
conceal the adjusting screws at the
front right and left on the lower edge
of the appliance.
Adjust the screws evenly on both
sides using a cross-slotted
screwdriver. Turn clockwise to tighten
the mechanism and anti-clockwise to
loosen the mechanism.
Refit the caps.
Height adjustment
Adjusting screws in the brackets
located at the top of the appliance are
used for aligning the appliance with
adjoining furniture units.
Turning the screws anti-clockwise
raises the appliance and clockwise
lower it.
You may also have to adjust the
depth again.
