a 2 recirculation grilles
(for recirculation mode only)
b 2 protective sheets
for use when fitting the tower.
c 1 directional unit
(for recirculation mode only)
d 1 flexible aluminium hose for con
-
necting the directional unit to the ex
-
haust socket on the motor unit.
e 2 hose clips for securing the ex
-
haust ducting.
f 1 non-return valve for fitting into the
exhaust connection on the motor unit
(for extraction mode only).
g Upper retaining plate B for secur-
ing the extension piece.
h Middle retaining plate C for addi-
tional stability for the tower.
i Lower retaining plate A for secur-
ing the canopy and the motor unit.
12 large headed screws 5 x 40 mm
and
12, S 8 plugs for securing the retaining
plates and the canopy.
2, M 6 locking nuts for securing the
motor unit.
4 screws 3.9 x 7.5 mm for securing the
tower and the extension piece.
Installation
17
