When fitting a DA 3180 or a DA 3190
appliance into a 60 cm unit, unscrew
the brackets on the deflector plate
whilst it is pulled out.
^
Lift the appliance up into the housing
from below, and engage in the
brackets.
Note for dismantling the cooker hood:
Undoing the screws on the left and
right inside the housing releases the
brackets, allowing the appliance to
be removed from the unit.
^
Push the cooker hood back against
the spacer strip.
^
Pull out the deflector plate.
^
Secure the appliance to the brackets
using two screws on each side.
^
Remove the protective film between
the deflector plate and the casing.
Installation
27
