^ Lift the appliance up into the housing
from below until it engages in the
brackets.
Note for dismantling the cooker hood:
Undoing the screws on the left and
right inside the housing releases the
spring mounts, allowing the
appliance to be removed from the
unit.
^
Push the cooker hood back against
the spacer strip.
^
Pull out the deflector plate.
^
Secure the appliance to the brackets
using two screws on each side.
Installation
25
