Aligning the deflector plate
^ The position of the deflector plate
can be brought forward by up to
35 mm using the adjusting screws on
either side of the deflector plate.
Align the deflector plate to the front of
the kitchen furniture units on either
side.
Fitting the grease filter
^
Remove the protective strip around
the edge of the grease filter.
Fit the grease filter.
^
To do this, pull the deflector plate
out.
^
Turn the grease filter so that the red
plastic guides are at the front and
facing upwards.
^
Fit the grease filter in the front of the
deflector plate, press it upwards and
push it in together with the deflector
plate. It will slide onto the fixing pins
at the back. Finally, push the grease
filter back a little more.
Installation
27
