Technical data
37
Fan motor* 120 W
Cooktop lighting 2 x 3 W
Total rated load* 126 W
Voltage, frequency AC 230 V, 50 Hz
Fuse rating 10 A
Mains connection cable length 1.5 m
Weight
DA 396-7 21 kg
DA 399-7 26 kg
DA 399-7 EXT 24 kg
* For EXT models, the rated load and extraction power will depend on the type of external
motor fitted.
Length of connection cable to external motor: 1.9 m
(special accessory for recirculation mode)
DUW 20 kit to convert from extraction mode to recirculation mode and charcoal
filter DKF12-1.
Note for test institutes
Note for comparative testing
Data quoted in the following data sheets was calculated in accordance with the
current standards EN61501 and EN60704-3. The distance between the area
being measured/stovetop and the underside of the rangehood is 600 mm and the
voltage 230V for test purposes. Testing is carried out without a non-return valve.
