Decor inserts
When handling them, take care not
to drop the decor inserts onto the
hob.
^ To remove the inserts, push them to
one side using the lever provided,
and lift them out.
Follow the directions shown by the
arrows in the diagram for each insert.
The inserts are designed so that the
angled edges face downwards.
Fitting the middle decor insert
^ Slide the insert in on the right-hand
side, then click it in on the left-hand
side.
Fitting the side inserts
^
First slide the side insert into the
guide rail at the side of the tower,
and then click them into place at the
outer edge.
Installation
29
