Connect the appliance to the electric
power supply.
Observe the "Important safety
instructions" and "Electrical
connection" warnings.
^ Place the cover panel onto the vent
and push until it clicks in place.
^ Press the On/Off button on the top of
the ventilation system.
The vent will rise and the fan will turn on.
^ Press and hold the 0/1 button until
the fan turns off.
Remove the transport protection
piece.
^
Remove the protective plastic from
the housing. If necessary, remove the
cover panel again.
^
Replace the cover panel and secure
it with 2 nuts.
^
Remove the backing from the grease
filters.
^
Place the filters in the bottom of the
vent. Press them downwards at the
edge so that they clip into the frame
at the top.
^
Press the 0/1 button to restart the
ventilation system.
^
Connect the vent duct.
When connecting the vent duct,
observe the "Important safety
instructions" and "Air extraction"
warnings.
Installation
33
