a AirClean
b Active AirClean 30 (black)
c HEPA AirClean 30 (white)
Do not use more than one exhaust fil‐
ter at a time.
When changing the filter please note:
1. If you wish to replace exhaust filter a
with filter b or c, it is essential that
you remove the filter grille before you
fit the new exhaust filter.
You must also activate the exhaust
filter change indicator (dia. 05).
2. If you wish to replace exhaust filter b
or c with filter a, it is essential that
you also fit the filter grille * (dia. 29).
* Filter grille - see "Optional accesso‐
ries".
Maintenance indicator with reset
button (dia. 32)
(on vacuum cleaners with + / - buttons)
The indicator lights up after approx. 50
hours of operation, which is equivalent
to about a year of average use.
The level of soiling of the dust compart‐
ment filter and the exhaust filter must
be checked at this point.
The indicator will need to be reset each
time these items are replaced. The vac‐
uum cleaner must be switched off to do
this.
Press the reset button .
The maintenance indicator will go out
and reset to zero.
The indicator can only be reset by
pressing the reset button after the
light has come on. Pressing the but‐
ton at any other time will have no ef‐
fect.
How to remove threads and hair from
the Electrobrush
Switch the Electrobrush and the va‐
cuum cleaner off, switch off at the
wall socket and remove the plug.
Release the vacuum cleaner (dia. 11)
and place it flat on the floor.
Turn the vacuum cleaner over.
Use scissors to cut any threads or
hairs which have wound around the
roller brush. There is a groove on the
roller to guide you (dia. 33).
Then run the vacuum cleaner to vac‐
uum up the bits.
The bottom of the suction hose can be
accessed to remove any heavy soiling
or blockages. Any large particles inside
it can then be easily removed.
Raise the vacuum cleaner into the
vertical position.
Press the release button on the tele‐
scopic tube to detach the suction ho‐
se handle (dia. 17).
To increase stability turn the elbow
joint at the bottom of the hose down‐
wards as illustrated until it clicks into
position above the retainer (dia. 18).
Unlock the hose connector by tur‐
ning it in the direction of the arrow
(dia. 34).
