If one of the screw positions is in the
cut-out area, e.g. of the built-in sink, at-
tach the fixing bracket supplied.
Pull the dishwasher approx. 5-10 cm
out of the recess.
Position the fixing bracket.
Push the dishwasher back into the re-
cess, adjust and screw into position
with a (3.9 x 22) screw.
For “Corian” or granite worktops there
is a special accessory to fix the dish-
washer to an adjacent kitchen unit.
Pull the dishwasher approx. 5-10 cm
out of its niche.
Fit the lug of each fixing bracket into
the guide hole on top of the dish-
washer, and then swing to the left or
right side respectively.
Push the dishwasher back into the
niche, align, and fix to the adjacent
kitchen unit(s) with 2 screws (3.5 x 15)
for each bracket.
Installing integrated “i” Dishwashers
