Existing plumbing:
If the standard 3/8" copper plumbing
for a dishwasher already exists with a
compression fitting and valve as pic-
tured:
Cut the 3/8" copper tubing after the
valve.
Install the 3/8" compression to 3/4"
MHT (Male Hose Thread) adapter
(supplied with the machine), as illus-
trated.
Connect the inlet hose to the existing
valve/adapter assembly.
Electrical wiring and components
should not come into contact with
any plumbing fixtures or hoses.
Do not, under any circumstances,
cut the intake hose. If the hose is
cut, the dishwasher will not work,
you will have a water leak and
you could be injured. If the hose
is too long, coil it neatly and
place it behind the machine.
Plumbing
61
