2. Fitting the facia panel
The dishwasher must not be used until the control panel has been correctly
fitted.
Dishwashers with selector dial
(G 601 - G 624, G 638 - G 686, G 801 - G 824, G 838 - G 884, G 975)
^ Attach cap a to push button switch.
^ Push the ventillation grille b
(depending on model) into position
so that the slats on the grille are
facing downwards.
^ Place the facia panel c in position
and use the six screws d to screw in
place through from the inside of the
door.
^
Attach selector e.
Installing integrated "i" Dishwashers
8
