1.Fitting protective cover plate
to worktop
The underside of the worktop is
protected against steam rising from the
machine by a special cover plate.
,
If two different materials meet up
at the front edge of the worktop, then
the join must be concealed by the
cover plate.
^
Remove the protective backing from
the cover plate.
^
Squeeze sealant from the tube
supplied all the way along the hollow
moulding in the cover plate.
^
Align the cover plate to the front
edge of the worktop in the middle of
the niche.
^
Use the tacks supplied to nail the
cover plate to the underside of the
worktop.
Worktops with wood or laminate
edging:
^ Nail the tacks through the holes
further back from the edge.
^ Use soapy water to wipe off any
excess sealant.
Installing integrated "i" Dishwashers
7
