Miele HM 21-100 Installations Plan

Rotary ironer HM 21-100
Last
modified:
05/14
Roller length mm
in
1005
39.57
Roller diameter mm
in
210 (incl. padding)
8.27 (incl. padding)
Machine dimensions W mm
D mm
H mm
W in
D in
H in
1280
415
986
50.39
16.34
38.82
Net weight kg
lbs
77
169.76
Max. floor load in operation N
756
Motor Roller drive W
rating Trough drive W
Fan W
150
100
-
Type of heating: electric V
3N AC 400 V
3 AC 230 V
1 AC 230 V
2 AC 230 V
Total rated load (EL) kW
4.55
4.55
3.45
3.45
Heater rating kW
4.4
4.4
3.3
3.3
Fuse rating
3
3N AC 380-415V 50-60Hz A
3 AC 220-240V 50-60Hz A
220-240V 50-60Hz A
2 AC 230V 60 Hz A
3 x 16
3 x 16
1 x 16
2 x 20
Connection EL
4
3N AC 380-415V 50-60Hz mm²
in²
3 AC 220-240V 50-60 Hz mm²
in²
220-240V 50-60 Hz mm²
in²
2 AC 230V 60 Hz AWG
5 x 1.5
5 x 0.0023
4 x 1.5
4 x 0.0023
3 x 1.5
3 x 0.0023
3 x AWG 14
Connections HD-Steam
Condensate
Gas
Exhaust air / exhaust gas
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Ironing performance
5
kg/h
lbs/h
according to DIN 11902
up to 23
up to 50.7
up to 23
up to 50.7
up to 19
up to 41.9
up to 19
up to 41.9
Rotational speed rpm
Roller Circumference speed m/min
ft/min
Contact pressure; norm. N/cm²
psi
2.0 - 5.3
1.3 - 3.5
4.26 – 11.48
0.5
0.725
Side colums
Material Roller
Trough
Sheet metal zinc-plated, stove-finished
Sheet metal zinc-plated
Aluminium extruded profile, hard anodized
Largest removable component
Roller: L = 1030 mm [40.55 in];  210 mm [8.27 in]
