Changing over the door
Remove any food from the door
shelves.
^
Close the door.
^ Remove cover a by sliding it
forwards from the back and then
lifting it off.
^ Remove cover b by pulling it
upwards.
Caution! The appliance door is not
secure once the hinge plate has
been removed.
^
Loosen screws d in upper hinge
plate c and pull it upwards and off.
^
Carefully lift the door off and place it
to one side.
^
Carefully release cover e from
above using a screwdriver and then
take it off together with retaining plate
f.
^
Then separate retaining plate f from
cover e by pushing it slightly to the
left. Then pull the cover forwards and
off.
^
Rotate retaining plate f by 180°.
^
Then fit cover e from the front over
retaining plate f, and slide it over to
the right. The writing must be visible.
^
Remove cover g, then rotate it by
180° and fit it on the opposite side.
^
Then fit cover e together with
retaining plate f on the opposite
side.
Changing the door hinging
