The appliance door can be aligned to
the housing using the outer long slots in
the lower hinge plate.
In the following illustration the door
is not shown in the closed position to
make it easier to see what happens
next.
^ Remove centre screw a from the
hinge plate.
^ Slightly loosen both outer screws b.
^ Align the door by sliding the hinge
plate to the left or right.
^
Then tighten screws b again. Screw
a does not need to be refitted.
Aligning the appliance
38
