^ Insert the cover strip into the space
between the appliance and the
wooden panel.
For side-by-side combinations, the
cover strips (on both sides of the
appliance) are applied to the
outermost spaces only.
^
Attach the light switch cover.
Attaching the toe-kick cover
The maximum height of the toe-kick
cover is 4" (101 mm) from the top of
the floor. Do not cover the ventilation
slits in the plinth. Risk of damage to
the appliance.
^
If required, cut the toe-kick cover to
the required length and height.
^
Attach the plinth to the appliance,
and put the included cover plates in
place.
Installing the appliance
60
