Miele KF 1801 Vi User Manual

Placing the appliance in the
niche
If you are installing two appliances
side by side, now secure the
appliances to one another (see the
instructions for the side-by-side
installation kit).
^ Unscrew the plinth facing.
^
Affix temporary protection to adjacent
furniture fronts.
^
Plug in the appliance a.
Connection should be made via a
suitable switched socket. The
socket should be close to the
appliance and easily accessible.
When installing two appliances side
by side, each appliance must have
its own separate socket.
^
Secure the cable to prevent it
becoming caught:
Tie a piece of string to the middle of
the cable, and as the appliance is
being pushed into the niche, pull the
cable forward underneath the
appliance b.
^ Carefully slide the appliance into the
housing unit.
If the appliance does not slide easily
into the niche (e.g. if the floor is
uneven),
^
screw out the rear feet slightly (see
"Aligning the appliance") and slide
the appliance into the niche.
Then push the appliance into the
niche, taking care not to damage
the electrical and mains water
connections.
^
Remove the temporary protection
from the adjacent furniture fronts.
Installation
83

Miele KF 1801 Vi Specifications

General

Child lock	-
Door hinge	Right
Control type	Sensor
Product color	Stainless steel
Reversible doors	Yes
Shelves material	Tempered glass
Door opening angle	115 °
Appliance placement	Built-in
Door panel included	No
Noise level	40 dB
Climate class	SN-T
Total net capacity	390 L
Total gross capacity	- L
Form factor	Upright
Fridge number of compressors	2
Star rating	4*
Freezer position	Bottom-placed
Freezing capacity	15 kg/24h
Freezer net capacity	80 L
Storage time during power failure	15 h
Fridge net capacity	253 L
Fridge number of shelves/baskets	4
Fresh zone compartment net capacity	57 L
Connected load	- W
Annual energy consumption	373 kWh

Weight and Dimensions

Depth	610 mm
Width	750 mm
Height	2127 mm
