Check the intake air
a Lock screw
b Air sleeve
Gap X must measure:
– 1/2" (13 mm) for natural gas
– 1/4" (6.5 mm) for LP gas
^
To adjust the gap loosen the lock
screw, a, and slide the air sleeve, b,
in or out as necessary.
^
Tighten the lock screw, a, and
reassemble the cooktop in the
reverse order.
Check all fittings for gas leaks
before reassembling the cooktop.
Converting KM 342 / 344
12
