Instructions for building-in
Prepare the worktop cut-out as illus-
trated.
Dimension ”B“ applies for a combina-
tion of appliances and is given on
the chart.
For Australia only
b cooktop
c worktop
d
removable barrier
For safety reasons, a removable bar-
rier must be installed as shown to en-
sure that inadvertant contact with the
hot underside is prevented.
The distance between the lower
edge of the worktop and the upper
edge of the removable barrier must
be a minimum of 125 mm.
Instructions for building-in
