Miele PFD 100 User Manual

Technical data
89
Model
Dishwasher
Normal
PFD101, PFD102i
XXL
PFD103SCi
Height of freestanding appliance 845mm
(adjustable + 35mm)
-
Height of built-in appliance 805mm
(adjustable + 65mm)
845mm
(adjustable + 65mm)
Height of building-in niche From 805mm
(adjustable + 65mm)
From 845mm
(adjustable + 65mm)
Width 598mm 598mm
Width of building-in niche 600mm 600mm
Depth of freestanding appliance 600mm -
Depth of built-in appliance 570mm 570mm
Weight Max. 60kg Max. 52kg
Voltage
Rated load
Fuse rating
See data plate See data plate
Power rating in off mode 0.4W 0.4W
Power rating when not switched
off
5.0W 5.0W
Network standby 0.9W 0.9W
Frequency range 2.4000–2.4835GHz 2.4000–2.4835GHz
Maximum transmission power < 100mW < 100mW
Water connection pressure 50 – 1000kPa 50 – 1000kPa
Cold or hot water connection Up to max. 60°C Up to max. 60°C
Mains water hardness Max. 36°dH Max. 36°dH
Delivery head Max. 1.0m Max. 1.0m
Drainage length Max. 4.0m Max. 4.0m
Ambient temperature 5°C to 40°C 5°C to 40°C
Relative humidity
maximum
linear decreasing to
80% for temperatures up to 31°C
50% for temperatures up to 40°C
Mains connection cable Approx. 1.7m Approx. 1.7m
Capacity 13/14 place settings 14 place settings
Noise emission values
Sound power LwA
Sound pressure LpA
46dB (A)
34.1dB (A)
45dB (A)
32.5dB (A)
Test certifications awarded EMC, VDE, radio and television suppressed
CE mark Machinery Directive 2006/42/EC
Manufacturer address Miele & Cie. KG, Carl-Miele-Straße 29,
33332 Gütersloh, Germany
