Miele PT 8331 G - Legende PT 833 x_Gas_GB.pdf

Installationsplan / Installation plan: PT 8331/8333/8335/8337
Datum / Date: 12.01.2011 Seite / Page: 8
Technical datasheet
Tumble dryer:
Heating:
PT 8331/8333/8335/8337
Gas (G)
Legend:
Abbreviations in bold type:
Connection required
en - GB
Abbreviations in circle with dashes:
Connection optional or required depending on model version
Optional extras:
UM
Miele plinth
UG 8350 box plinth
Height
mm
127
Width
mm
900
Depth
mm
868
BS
Concrete plinth
Quality and density of concrete must comply with load.
Concrete plinth must be firmly secured to floor!
Recommended height
mm
100
Minimum height
mm
50
Width min.
mm
900
Width:min.
mm
1100
Machine connections:
Electrical
connection
1. Standard voltage (as supplied)
V
1N AC 220 - 240
Frequency
Hz
50
Rated load
kW
0.8
Fuse rating
A
1 × 10
Connection cable, min. cross-section
mm²
3 × 1.5
Cable screw connector
M 20
Connection cable (to be ordered separately)
Electrical connection must comply with national regulations.
Connection using multi-pole wall socket in compliance with
IEC/EN 60309 and IEC/EN 60947 is recommended in order to
simplify electrical tests.
If machines are hard-wired, a multi-pole mains switch must be
provided on site.
A wall socket or mains isolator must be accessible after
installation.
Equipotential
bonding
Connection with male thread
mm
10 × 35
with washers and nut.
M
10
Accessories to be ordered separately
If necessary, equipotential bonding with good galvanic
contact must be provided in accordance with all appropriate
national and local regulations.
