Note
The kit, Mat. no. 04451340 for PW 610x, PW 613x, PW 616x and PW 620x, contains the following:
• 1 container
• 1 cap
• 1 seal
• 1 clamping ring
• 1 bolt M8 x 150
• 2 washers 8.4
• 1 nut M8
• 11 connection hoses
• 4 connection pipes 32 mm dia. x 1.5
• 8 hose clips SGL 25 - 40
• 1 branch piece
• 1 hose clip SGL 16 - 25
• 1 mounting bracket, octoblue
• 1 circulation valve T 28, AB 81-A 04, 220 V 50 Hz
• 1 wiring harness - Drain valve
• 1 machine socket GDM 20, 11 grey
• 1 connection pipe 32 mm dia. x 1.5
• 6 hose clips SGL 40 - 60
• 1 filter housing
• 1 fluff filter
• 1 lid
• 1 handle
• 2 raised-head self-tapping screws 4.2 x 9.5
• 1 immersion pump SPA 500
x
Note
The kit, Mat. no. 04451340 for PW 610x, PW 613x, PW 616x and PW 620x, also contains the following:
• 1 cable holder 98 x 2.5
• 1 cable holder 200 x 4.8
• 2 hose clips SGT 25 - 40 / 9 DIN 3017
• 1 connection pipe 32 mm dia. x 1.5
• 1 cable screw connector MZ PG 9 6 - 8
• 1 counter nut PG 9 MS
• 1 bracket
• 4 nuts, stainless steel, M5
• 4 washers, stainless steel, B5.3
• 1 bend 70 x 87 PP
• 1 sleeve DIN 19560, dia. 70 mm
• 1 bend 70 x 87 PP
• 2 pipes DIN 19560 HTEM 70 x 150
• 1 branch piece DIN 19560 70 x 70 x 87
• 1 pipe DIN 19560 HTEM 70 x 150
• 1 bend 70 x 87 PP
• 1 bracket
• 1 drain valve MDB
• 1 wiring harness - Drain valve
• 2 hexagonal-head self-tapping screws 4.2 x 13
• 2 speed nuts, stainless steel, B4.2
• 1 overflow
• 1 drain set
• 1 bend DIN 19560, 40 x 87
Produktgruppe 512 Umbau- und Montageanweisung
14 von 60 M.-Nr. 04598534
16.12.2011 Diese Unterlagen dürfen ohne unsere Genehmigung weder vervielfältigt noch Dritten zugänglich gemacht werden. Eigentumsrechte vorbehalten.
