Note
The kit, Mat. no. 04451340 for PW 610x, PW 613x, PW 616x and PW 620x, also contains the following:
• 1 pipe 173 x 40
• 2 bends 70 x 87 PP
• 1 branch piece 70 x 50 x 87, DIN 19560
• 1 connection stub
• 1 collar DIN 4060, HTGM 40/50 C
• 1 branch piece
• 1 ring
• 1 connection stub
• 2 hose clips SGL 70 - 90
• 1 branch piece 70 x 50 x 87, DIN 19560
• 1 pipe DIN 19560 50 x 40
• 1 bend 70 x 87 PP
• 8 hoses 1 1/4" 32 x 5.5
• 1 wiring harness - Water recycling
• 1 terminal strip, 6-pole
• 1 sticker 1 - 6,10 x 68
• 2 raised-head self-tapping screws 3.5 x 11
• 1 accessory - Information sheet
• 1 accessory - Installation
• 1 initial kit for water recycling
• 1 hose sub-assembly WRG 02
• These fitting instructions - Connection for water recycling
List of illustrations (PW 610x, PW 613x, PW 616x, PW 620x):
– Fig. 1: Mixer box cover plate removal
– Fig. 2: Drain hose disconnection from mixer box
– Fig. 3: Water recycling intake on mixer box
– Fig. 4: Drilling out water recycling intake on mixer box
– Fig. 5: Water recycling intake viewed from liquid dispensing cover plate
– Fig. 6: Water recycling intake
– Fig. 7: Mixer box cover plate fitting
List of illustrations (PW 6241, PW 6321):
– Fig. 8: Connection hose pre-assembly
– Fig. 9: Suds container preparation
– Fig. 10: Connection hose fitting
– Fig. 11: Angle connector fastening and holder
– Fig. 12: Connection hose fastening
– Fig. 13: Mixer box cover plate in fitted position
List of illustrations (WS 5101, WS 5141, WS 5191, WS 5240, WS 5320):
– Fig. 14: Connection hose pre-assembly
– Fig. 15: Fitting in the machine
– Fig. 16: Intake hose - WS 5101, WS 5141
List of illustrations (WRG 02 water recycling system fitting):
– Fig. 17: Mounting bracket
– Fig. 18: Tank fitting
– Fig. 19: Tank with angled hoses
– Fig. 20: Filter unit assembly
– Fig. 21: Hose connections
