Miele WS 5191 - Assembly of Water Recycling Components; Tank Installation for WRG02 System

x
X Y
WS 5101 280 280
WS 5141 280 280
WS 5191 340 203
WS 5240 476 205
WS 5320 317 205
Table 1: Trimming dimensions
– Shorten the suds container / connection strip connection hose depending on the machine in which it is to be fitted and carry out
pre-assembly, Fig. 14 and Table 1.
– Remove the seal with metal plate from the suds container. Reuse the seal.
– Fit the seal and connection hose in the suds container and secure with the M5 x 12 screw, washer and M5 nut (self-locking),
Fig. 15, Pos. 1.
– Connect the connection hose stub to the connection strip, Fig. 15, Pos. 2.
– With the WS 5101, WS 5141, shorten the imbalance switch feeler by 45 mm.
WRG02 water recycling fitting
Tank fitting:
x
Warning!
Before commencing work, ensure that the wall can support the weight of the system. Weight of tank: Approx. 200 kg
Note
For mounting bracket positioning dimensions, see the installation plan.
– Hold the mounting bracket as a template on the wall and mark the positions where holes must be drilled.
– Drill 10 mm dia. holes.
x
Warning!
Note the different height dimensions when drilling the holes.
Note
The fastenings supplied can be used for German concrete quality ≥ B 15 and solid brickwork German quality ≥ MZ 15.
For other wall types, appropriate fastenings must be provided on site.
– Fit M6 x 16 bolts in the top fixing nuts.
– Hang the tank in the top fixing holes.
– Fit the remaining bolts (6x) and tighten them.
– Fasten the pre-assembled angled hoses to the container cap with 32 - 50 mm hose clips, Fig. 19.
– Slide the pipe connectors,Fig. 19, Pos. 1, into the angled hoses and secure them with 32 - 50 mm hose clips.
x
Warning!
Note the position of the vent hose.
– Connect the connection hose with drain valve to the tank with a 40 - 60 mm hose clip.
– Connect the drain angled hose to the drain valve and secure it with a 40 - 60 mm hose clip.
Produktgruppe 512 Umbau- und Montageanweisung
17 von 60 M.-Nr. 04598534
