Note
Installation kit 04451340 for PW 610x, PW 613x , PW 616x and PW 620x contains:
• 1 container
• 1 cap
• 1 seal
• 1 clamp ring
• 1 hex screw M 8 x 150
• 2 washers 8.4
• 1 hex nut M 8
• 11 hoses
• 4 pipes 32 DRM x 1.5
• 8 hose clips SGL 25-40
• 1 branch piece
• 1 hose clips SGL 16-25
• 1 panel, octoblue
• 1 circulation valve T 28, AB 81-A 04, 220 V / 50 Hz
• 1 drain valve wiring harness
• 1 socket GDM 20, 11 gray
• 1 pipe 32 DRM x 1.5
• 6 hose clips SGL 40-60
• 1 filter housing
• 1 lint trap
• 1 lid
• 1 handle
• 2 screws 4.2 x 9.5
• 1 immersion pump SPA 500
x
Note
Installation kit 04451340 for PW 610x, PW 613x , PW 616x and PW 620x also contains:
• 1 cable guide 98 x 2,5
• 1 cable guide 200 x 4,8
• 2 hose clips SGT 25-40 / 9 DIN 3017
• 1 pipe 32 DRM x 1.5
• 1 cable connection MZ PG 9 6-8
• 1 locknut PG 9 MS
• 1 angle bracket/elbow
• 4 stainless-steel M 5 hex nuts
• 4 stainless-steel B 5.3 washers
• 1 elbow 70 x 87 PP
• 1 bushing DIN 19560, DN 70
• 1 elbow 70 x 87 PP
• 2 pipes DIN 19560 HTEM 70 x 150
• 1 branch pipe DIN 19560 70 x 70 x 87
• 1 pipes DIN 19560 HTEM 70 x 150
• 1 elbow 70 x 87 PP
• 1 angled bracket
• 1 drain valve MDB
• 1 wiring harness drain valve
• 2 hex screws 4.2 x 13
• 2 stainless-steel B 4.2 nuts
• 1 drain
• 1 drain fitting
• 1 elbow DIN 19560, 40 x 87
Produktgruppe 512 Umbau- und Montageanweisung
56 von 60 M.-Nr. 04598534
16.12.2011 Diese Unterlagen dürfen ohne unsere Genehmigung weder vervielfältigt noch Dritten zugänglich gemacht werden. Eigentumsrechte vorbehalten.
