A In a side-by-side set-up of washer and dryer, the two stands have to be bolted together, refer Abb. 6 and Abb. 7.
x
Warning!
Washer/stand and dryer/stand have to be aligned with each other.
A Snap the connectors into the washer/stand combination.
A Push the washer/dryer/stand combo together until the connectors engage.
x
Note
Connectors have to lock with a visible and audible snap.
A After the washer/stand and dryer/stand are joined, check again that the combo is standing securely, and correct if necessary.
A Put the drawers into the washer and dryer stands, refer Abb. 2.
A Adjust the front panel, refer Abb. 8.
A Remove the caps.
A Loosen the retaining screws on the side of the front panel, do not remove them completely..
A Adjust the panel on the stand.
A Tighten the retaining screws on the side of the front panel.
A Put the caps back.
A Set up the drawer dividers, refer Abb. 9.
A Washer/Dryer/stand Disassembly
A To disassemble, follow the steps of these installation instructions in reverse order.
A Release the snap connectors using the special tool in the kit, refer Abb. 10.
am
fr
Pièces nécessaires
x
Nombre Mat.-Nr. Désignation
1 06447280 Montage du socle lave-linge/sèche-linge 430
1 00253532
Jeu de montage de fixation au sol, nécessaire en cas d'installation d'un
sèche-linge seul
Product Group 19 Conversion and Fitting Instructions
5 von 10 Mat. no. 06694601
14.12.2006 This information should not be duplicated or passed on without Miele approval. All rights reserved.
