MM560 Installation Instructions 14
Mounting Pull-to-Open Opener to Gate
Gate Opener Installation
OPEN gate and re-attach opener with clevis pin. Check for level.
Clamp securely.
U
O
Z
N
7
Secure post pivot bracket to post bracket when clearances are
OK (Step 5) in both open and closed positions.
9
8
Mark middle of post bracket slots on fence post. Mark middle of
gate bracket slots on gate cross support.
Remove clamps, post, gate brackets, and opener. Then use a
hammer and center punch to dimple hole positions for drilling.
P
S
Y
R
11
10
Drill 3/8” holes completely through gate post and gate cross
support.
Attach post bracket assembly to fence post. NOTE: Must be
through bolted.
Your Property
2
6
1
To Next Page
