Typical installation diagramTypical installation diagram
6
DimensionsDimensions
Safety valve
Pump
Alternative
pump position
Flow Return
Overflow
Mains
cold
water
320
390 465
540
480
600
View on arrow 'A' Front view
The expansion vessel is usually
connected on the inlet side of the
pump on the system return. For
systems exceeding 90
o
C contact
our technical department for
advice.
See notes on pipework sizing on
page 5.
