Expansion slots and ports
Product code ATLGM&EG18-EA
CPU Dual-core 88F3720 1.2 GHz
CPU architecture ARM 64bit
Size of RAM 256 MB
RAM type DDR3L
Storage 16 MB, Flash
Number of 1G Ethernet ports 1
LTE modem R11mL-EG18-EA
TAC 86981604
LTE Category 18 (1.2Gbps Downlink, 150Mbps Uplink)
LTE bands 1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 7 (2600MHz) / 8 (900 MHz) / 20 (800MHz) / 28 (700MHz) / 38 (2600MHz) / 40 (2300MHz)
/ 41 (2500MHz)
3G Category R8 (42.2Mbps Downlink, 11.2Mbps Uplink)
3G Bands 1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 8 (900MHz)
Dimensions 315 mm diameter x 170 mm depth
Operating system RouterOS, License level 3
Operating temperature -40°C to +70°C
SIM slot usage
SIM card slot is designed to be used with Micro SIM cards.
Nano SIM cards have different thicknesses and usage with an adapter is not recommended.
Reset button
The reset button has three functions:
Hold this button during boot time until the LED light starts flashing, release the button to reset RouterOS configuration (total 5 seconds);
Keep holding for 5 more seconds, LED turns solid, release now to turn on CAP mode. The device will now look for a CAPsMAN server (total of 10
seconds);
Or Keep holding the button for 5 more seconds until LED turns off, then release it to make the RouterBOARD look for Netinstall servers (total of
15 seconds);
Regardless of the above option used, the system will load the backup RouterBOOT loader if the button is pressed before power is applied to the device.
Useful for RouterBOOT debugging and recovery.
