Milesight Technology MS-C2981-PB - Page 9

4
3. Vandal-proof Mini Dome Network Camera
Figure 1-3-3 Vandal-proof Mini Dome Network Camera
Note:
1) Error LED Indicator: Error LED Indicator is on when the device starts up or runs error.
2) Reset Button: Press “Reset” button for 5 seconds, then the device will be restored to factory
default.
3) Only PoE is available for power supply.
IR LEDs
Light Sensor
Lens
Ethernet Port (PoE)
microSD/SDHC/SDXC
Card Slot
Microphone
Screw
Power and System LED Indicator
Reset
