Milestone STA - SafetyWand Locking and Preparation

BASIC
OPERATION
To Lock:
Once in the fully protracted position,
depress the forward portion of the
CONTROL TAB to lock.
To Unlock:
Depress the back portion of the
CONTROL TAB and release.
Fig. 5
Fig. 6
Preparation:
1. Turn drive unit on.
2. Remove the sterile SafetyWand™ handpiece from package. Maintain
sterility.
3. Attach the needle:
a. Hold the SafetyWand™ in one hand.
b. Attach a standard luer lock needle by depressing the back portion
of the control tab and by sliding it forward. To lock in the protracted
position, slide control tab forward and depress the forward portion
of control tab.
c. While securely holding the SafetyWand™, place the end of a
standard luer lock needle into the open end of the SafetyWand™
and rotate until firmly secure.
d. Place the handpiece on the side of the drive unit when not in use.
Once secured, retract the needle by depressing the back portion of
the control tab and pull handpiece straight out of cap. Do not twist.
(Cap remains in the receptacle on side of unit.) While not in
use, replace the retracted handpiece onto the cap on the side of the
drive unit.
4. Load the anesthetic into the SafetyWand™ and attach the cartridge holder
to the drive unit by twisting the holder counter-clockwise approximately ¼
turn in the STA drive unit. The STA will automatically purge the air from
the tubing and needle. The handpiece is now primed and ready for use.
