THE MILLENNIUM SIGNATURES B-1220/B-2045 BENCH
FIXTURESROLL MARKING APPLICATIONS
NOTE: To avoid short circuits (See illustration 1-A), do not cross the leads, or make
contact between the marker and the grounded surface when both surfaces are bare.
DIRECTIONS:
A) Plug the black wire into the black jack of the bench xture.
B) Remove the top plate (carbon) from the xture.
C) Pour the recommended electrolyte into the well.
E) Replace the top plate.
F) Place a deep etch pad or monopad (blue side out) on the top plate, and secure it with
the enclosed “O” ring. Make certain that the sides of th pad are tucked down inside the
well. This will insure that your pad will draw the uid without operator assistance. Use
either a B-1220-3, B-1220DE, B-2045-3, or a B-2045DE monopad for best results.
G) Place the stencil over the pad with the reading face down, as if to read the
information from the bottom of the xture. Slide the “O” ring over the stencil pad and
top plate until it snaps into the machined groove.
H) Connect the hand ground (at bottom or knife edge) to the ground jack of your
power unit.
I) Place the substrate (surface to be marked) on the stencil in front of the reading.
Place the hand ground on the substrate, and roll the substrate over the reading, using
moderate pressure.
J) Use Millennium Signatures’ neutralizer to neutralize any area of the substrate that
has come into contact with the electrolyte.
K) For added protection, apply Millennium Signatures’ Rust Preventative Oil (RPO).
It is always a good practice to apply oil to ensure rust and corrosion protection.
FOR ADDITIONAL INFORMATION CONTACT MILLENNIUM SIGNATURES
Phone: (905) 639-0909
Fax: (905) 639-0919
E-mail: info@millenniumsignatures.com
THANK YOU!
