Pairing Procedure (over radio)
1. Turn on the receiver.
2. With the transmitter off: press and hold down the lower left-hand soft button, then press/release
the power button. When the following screen appears, release the soft button:
3. Switch the receiver into Pairing mode with the magnet, as described above - its STATUS LED will
remain solid red and its LINK LED will flash green with a 50% duty cycle.
4. Initiate pairing on the transmitter by pressing the “PAIR” soft button. The receiver’s LINK LED will
flash fast green during pairing, and the transmitter will display the following:
Pairing
1. Power up receiver
2. Place transmitter close to receiver
3. Wait for receiver to indicate pairing
4. Press PAIR
Pairing initiated…
Pairing
1. Power up receiver
2. Place transmitter close to receiver
3. Wait for receiver to indicate pairing
4. Press PAIR
PAIR
