MD - 2000A LOGIC DIAGRAMS
CW & CCW operation
clockwise counterclockwise
IC2 pin 6
IC2 pin 11
IC4 pin 4
IC4 pin 3
1TB 2
Speed Out
CW
1TB 3
Speed Out
CCW
PL-361 11
