Fastener Torque Requirements
PELLERIN MILNOR CORPORATION
Table 6: Torque Values for Applications of LocTite 222
Bolt Grade
Grade 2 Grade 5 Grade 8 Grade BC
Bolt Size
Pound-
inches
N-m
Pound-
inches
N-m
Pound-
inches
N-m
Pound-
inches
N-m
1/4 x 20 60 7 96 11 132 15 108 12
1/4 x 28 72 8 108 12 144 16 -- --
Table 7: Torque Values for Applications of LocTite 242
Bolt Grade
Grade 2 Grade 5 Grade 8 Grade BC
Bolt Size
Pound-feet N-m Pound-feet N-m Pound-feet N-m Pound-feet N-m
5/16 x 18 11 15 17 23 25 34 22 30
5/16 x 24 13 18 19 26 27 37 27 37
3/8 x 16 20 27 31 42 44 60 38 52
3/8 x 24 23 31 35 47 50 68 -- --
7/16 x 14 32 43 49 66 70 95 61 83
7/16 x 20 36 49 55 75 78 106 -- --
1/2 x 13 49 66 75 102 107 145 93 126
1/2 x 20 55 75 85 115 120 163 -- --
9/16 x 12 70 95 109 148 154 209 134 182
9/16 x 18 78 106 121 164 171 232 -- --
5/8 x 11 97 132 150 203 212 287 186 252
5/8 x 18 110 149 170 230 240 325 -- --
Table 8: Torque Values for Applications of LocTite 262
Bolt Grade
Grade 2 Grade 5 Grade 8 Grade BC
Bolt Size Pound-feet N-m Pound-feet N-m Pound-feet N-m Pound-feet N-m
3/4 x 10 155 210 240 325 338 458 296 401
3/4 x 16 173 235 267 362 378 512 -- --
7/8 x 9 150 203 386 523 546 740 477 647
7/8 x 14 165 224 426 578 601 815 -- --
