Milnor MCR12E5 - Page 73

R
Pellerin Milnor CorporationPellerin Milnor Corporation
P. O. Box 400, Kenner, LA 70063-0400
Litho in U.S.A.
Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to
assemblies are referred to in the "Used In" column to identify which components belong to an assembly. The item
numbers (1, 2, 3, etc.) assigned to components relate the parts list to the illustration.
Parts List—Coin Acceptor & Vault
BMP040093/2010332B
(Sheet 2 of 2)
.
---------------------------------------------------------------------ASSEMBLIES------------------------------------------------------------------
A GCM33002 COIN ASSY INSTALL 2314MCR09
-------------------------------------------------------------------COMPONENTS------------------------------------------------------------------
all 1 38C085 REJ.W/LOCK-MECH 230V CASTIC
all 2 W3 40029 2314MCR09 COIN VAULT WELD
all 3 38C152KI COIN LOC BX KEY-INDV.#71942-XD KEYED INDIVIDUALLY
all 3 38C152KA COIN LOC BX#71942-XD KEY-ALIKE KEYED ALIKE
All 4 03 40029B BEZZLE COIN VAULT
