Pellerin Milnor CorporationPellerin Milnor Corporation
P. O. Box 400, Kenner, LA 70063-0400
Litho in U.S.A.
Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to
assemblies are referred to in the "Used In" column to identify which components belong to an assembly. The item
numbers (1, 2, 3, etc.) assigned to components relate the parts list to the illustration.
Parts List—Soap Chute
BMP060005/2009412B
(Sheet 3 of 3)
.
-------------------------------------------------------------------COMPONENTS------------------------------------------------------------------
all 1 AWS33006 DRY AND LIQUID SUPPLY OPL
all 2 03 40039B GASKET SOAP CHUTE
all 3 03 40039C COVER SOAP CHUTE
all 4 03 40039H FLEXIBLE TUBE=SOAP CHUTE 4.25"
all 5 27A065 HOSECLAMP 1.56"-2.5"SSSCR#32
all 6 03 40043 INLET LIQUID SUPPLY
all 7 W3 40039D WELD HINGE COVER SOAP CHUTE
All 8 20C040B SUPERFLEX CLR RTV SIL 10.2OZ
All 9 12P015D CABLE CLIP TINN#C23214-017
All 10 60E006C PVC TUBING NYL.REINF.5IDX.75OD
All 11 27A044 HOSECLAMP 5/8"ID BREEZE#6706SS
