BMP120032/2012383A
(2/2)
R
Pellerin Milnor CorporationPellerin Milnor Corporation
P. O. Box 400, Kenner, LA 70063-0400
Litho in U.S.A.
Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components.The item letters (A, B, C, etc.) assigned to assemblies are referred to in the "Used
In" column to identify which components belong to an assembly. The item numbers (1, 2, 3, etc.) assigned to components relate the parts list to the
illustration.
Parts List—Water Schematic
---------------------------------------------------------------------ASSEMBLIES------------------------------------------------------------------
A AVW14822A 36V5 H+C H20 VALASSY-ELECT 5 5
B AVW14822 36VU H+C H20 VALASSY-ELECT
C AVW11912V 4226V 1.25ELECT H20 VALVE ASSY 42026V6J, 42030V6J
AB D GWS14802 INSTAL=SUPPLY INJ ASSY 36RWP
C E GWS119002 INSTAL=SUPPLY INV ASSY RWP
-------------------------------------------------------------------COMPONENTS------------------------------------------------------------------
AB 1 96P056C37 3/4"NC 110V PARKER #12F24C2248AAFPH05
C 1 96P152A37 1+1/4"NC 110V W/LEADS BURKERT #US10360
AB 2 96P042VA37 DIN CONNECTOR W/CABLE BURK not used 42026V6, 42030V6
all 3 96D350A37C DRNVAL 3"N/O 120V50/60C W/COVER
all 4 96P058A37 1/4"NPT X 1/8"ORIFICE 120V 5/6
all 5 96J030FF 1/2"PRESSREG SET 28# FEMXFEM
all 6 96M001 1/2X3/8" RELIEF VALVE SET31#
all 7 60E004TE 1/4"OD X.170"ID NYL(BLK)TUBING
all 8 30N100 PRESSGAUGE 1/8"BACKCN.0-30PSI
all 9 60E085C18K HOSE ASSY=1/2"X18.5"LG+ENDS
all 10 96P013G37 3/4" 2WAYPLASTCVAL 120V60C
all 11 51T030 Y-STRAINER 3/4" CAST IRON
all 12 96P040A37 3/4"STEAMVAL120V50/60C 150PSI
A 13 AVS14806 36V5J STEAM NOZZLE ASSY 3/4"
BC 13 AVS14805 *STEAM NOZZLE ASSY 3/4"
36021V J,36026V J
36021V7J,36026V7J
96
