Pellerin Milnor CorporationPellerin Milnor Corporation
P. O. Box 400, Kenner, LA 70063-0400
Litho in U.S.A.
BMP120030/2012383A
(4/4)
Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components.The item letters (A, B, C, etc.) assigned to assemblies are referred to in the "Used
In" column to identify which components belong to an assembly. The item numbers (1, 2, 3, etc.) assigned to components relate the parts list to the
illustration.
Parts List—Water Inlet Assemblies
---------------------------------------------------------------------ASSEMBLIES------------------------------------------------------------------
A AVW14822 36VU H+C H20 VALASSY-ELECT 36021V7J, 36026V7J
B AVW14822A 36V5 H+C H20 VALASSY-ELECT 36021V5J, 36026V5J
C AVW11912V 4226V 1.25ELECT H20 VALVE ASSY 42026V6J, 42030V6J
-------------------------------------------------------------------COMPONENTS------------------------------------------------------------------
all 1 5SP0PHFSS NPT PLUG 3/4 SQ SOLID STL/ZINC
AB 2 5S0PNFA NPT TEE 3/4" GALMAL 150#
C 2 5S1ENFA0P1 NPTTEE 1.25X1.25X3/4 GALMA150#
AB 3 5N0P05AG42 NPT NIP 3/4X5 TBE GALSTL SK40
C 3 5N1E05AG42 NPT NIP 1.25X5 TBE GALSTL SK40
AB 4 96P056C37 3/4"NC 110V PARKER #12F24C2248AAFPH05
C 4 96P152A37 1+1/4"NC 110V W/LEADS BURKERT #US10360
all 5 96P042VA37 DIN CONNECTOR W/CABLE BURK
AB 6 5SP1ADESC NPT PLUG 1" SQ CORED GAL CI
C 6 51P055 NPTPLUG 1.5 SQCORED GALCI 125#
AB 7 5S1ANFA0P1 NPT TEE 1X1X3/4" GALMAL 150#
C 7 5S1KNFA1E1 NPTTEE 1.5X1.5X1.25 GALMAL150#
A 8 5N1A08AG42 NPT NIP 1X8 TBE GALSTL SK40
B 8 5N1A06KG42 NPT NIP 1X6.5 TBE GALSTL SK40
C 8 5N1K07AG42 NPT NIP 1.5X7 TBE GALSTL SK40
A 9 5N1A16AG42 NPT NIP 1"X16"GALVSTL SCH40
B 9 5N1A17RG42 NPT NIP 1X17.875TBE GALSTL S40
C 9 5N1K16AG42 NPT NIP 1.5X16 TBE GALSTL SK40
AB 10 5SL1ANFA NPT ELBOW 90DEG 1" GALMAL 150#
C 10 5SL1KNFA NPT ELBOW 90DEG 1.5" GALMAL 15
B 11 5N1A03KG42 NPT NIP 1X3.5 TBE GALSTL SK40
C 11 5N1K06AG42 NPT NIP 1.5X6 TBE GALSTL SK40
AB 12 5SL1ANFA0P NPTELB 90DEG 1X3/4 GALMAL 150#
C 12 5SL1KNFA1E NPTELB 90D 1.5X1.25GALMAL 150#
AB 13 5N0P05AG41 NPT NIP 3/4"X5"TOE GALVSTL S40
C 13 51E099STC DIXON 1.25KINGNIP NPTEND#STC15
all 14 5SB0P0EBEO HEXBUSH 3/4X1/4 BRASS 125#
all 15 53A026A HEXPIPNIP.25X.25 AND#122A-B
all 16 96P058A37 1/4"NPT X 1/8"ORIFICE 120V 5/6
all 17 51E507D HOSESTEM BRASS 1/4MPX5/8HOSEID
all 18 27A040 HOSECLAMP 7/16-25/32SS W/SCREW
all 19 60E007C TUBING NYL.REINF.5/8"IDX.8750D
A 11 5N1A06KG42 NPT NIP 1X6.5 TBE GALSTL SK40
