Parts List—Soap Chute Assembly
BMP870042/2012383B
(Sheet 1 of 1)
.
-
--------------------------------------------------------------------------ASSEMBLIES--------------------------------------------------------------------------
W AD 02 013A 80182C SOAP CHUTE ASSY - BALCOM 36TMW,OEW,CPE,NSP,BWP
X GGS14804 89063# SOAP CHUTE INSTL 36RWP 36021/36026V5J,36026V7J
36021/36026QXX
3621C4E
Y GGS119002 89063D SOAP CHUTE INSTL 42RWP 42026V6J,42030V6J
42026QXX
Z SA 02 065 81223B COVER ASSY=SOAP CHUTE CONTAINS1&2
-------------------------------------------------------------------------COMPONENTS------------------------------------------------------------------------
-
Z 1 02 02739 91046B SOAP CHUTE COVER YOUR MATL
Z 2 02 02706 87456A HINGE=SOAP CHUTE
X,Y 4 02 11932 86361B PLATE-ANTI SPLASH 42 RWP
W,X 5 02 02326A 78252B GUARD-BALCOM SOAP CHUTE
Y 5 02 02326B 89063B GUARD-RWP SOAP CHUTE SPCL
X 6 02 11936 87163C PLATE=ANTISPLASH RWP
Y 6 02 11936A 89063C ANTI-SPLASH PLATE RWP SPCL
X,Y 3 02 10262A 78327B SPLASHPLATE,REAR=42Q SOAPCHT
Soap Chute Assembly
