Pellerin Milnor CorporationPellerin Milnor Corporation
P. O. Box 400, Kenner, LA 70063-0400
Litho in U.S.A.
Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to
assemblies are referred to in the "Used In" column to identify which components belong to an assembly. The item
numbers(1, 2, 3, etc.) assignedto components relate the partslist tothe illustration.
Parts List—5 Compartment Supply
BMP860026/2012383B
(Sheet 2 of 2)
.
---------------------------------------------------------------------ASSEMBLIES------------------------------------------------------------------
V GWS119002 INSTAL=SUPPLY INV ASSY RWP 42026Qxx, 42026V6J
42030V6J
W GWS14802 INSTAL=SUPPLY INJ ASSY 36RWP 36021,36026Qxx
36021/36026V5J,36026V7J
X AWS119001A SUPPLY INJ ASSY 3621Q V-W , 36021BWP
Y AWI11007A MANIFOLD=5 FLUSH 36/42Q'S X
Z SA 09 047 COVER=SUPPLY INJECTOR X (CONTAINS ITEMS
2-3)
-------------------------------------------------------------------COMPONENTS------------------------------------------------------------------
X 1 Y2 09096R *SUP-CHOTE 5FLUSH RWP+
Z 2 02 09182 LID=SUPPLY INJECTOR
Z 3 02 09105 HINGE=VALVE ENCLOSURE STNSTL
V,W 4 02 09113 SUPPLY CHUTE SHELL GASKET
X 5 W2 11953 *WLDMT=INJECTOR TUBE ENCL RWP
V 6 02 10266B BRACE SUPPLY INJECTOR 42RWPE
W 6 02 10266C BRACE-SUPPLY INJECTOR 36RWPE
7 5SL0GBEL NPTELB 45DEG STRT 3/8 BRASS125
8 5SCC0GBE NPT COUP 3/8 BRASS 125# 103A-C
9 27A040 H0SE CLAMP 5/16-7/8 SS SCR
10 51E505 HOSESTEM BRASS 3/8H XMPT
89
