Pellerin Milnor CorporationPellerin Milnor Corporation
P. O. Box 400, Kenner, LA 70063-0400
Litho in U.S.A.
Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to
assemblies are referred to in the "Used In" column to identify which components belong to an assembly. The item
numbers(1, 2, 3, etc.) assignedto components relate the partslist tothe illustration.
Parts List—Flushing Manifold
BMP900019/2012383B
(Sheet 2 of 2)
.
---------------------------------------------------------------------ASSEMBLIES------------------------------------------------------------------
Y AWI14001 ASSY=FLUSH MAN 5SUP F8P 120V 36021F8P
Z AWI11007A MANIFOLD=5 FLUSH 36/42Q'S 36021/36026/42026QXX
36021/36026V5J,
36026V7J,42026V6J
42030V6J, 3621BWP
-------------------------------------------------------------------COMPONENTS------------------------------------------------------------------
1 W2 11950S *WLDMT=MAINFOLD-SUPPLY INJ SS
Y 2 02 11952 HOUSING-SUPPLY VALVES
Y 3 02 14730 +FLUSH MNT BRKT TOP
Y 4 02 14730A +FLUSH MNT BRKT BOTTOM
5 02 11954 BKT-3/4" PIPE SUPPORT
6 96P013G37 3/4" 2WAYPLASTCVAL 120V60C
Z 7 02 11952 HOUSING-SUPPLY VALVES
Z 8 02 14833 SUPPLY BRACE 3621 RWP
Z 9 02 11955 REAR PL.-SUPPLY VALVE HSNG
91
