MJC680-2 Rev AA April 2019
FIGURE 18 — 1-SPEED PUSHBUTTON STATION
Parts List for Pushbutton, 1-Speed
Ref. no Description Part No. Qty
1 Pushbutton Station and Control Cable Assembly
6 ft Cable Length PB2100-6 1
11 ft Cable Length PB2100-11 1
16 ft Cable Length PB2100-16 1
2 Pushbutton Station Assembly (2-Button, 1-Speed) 36900R 1
3 Enclosure 36998R 1
4 Control Cable Assembly
6 ft Cable Length PBC2100-6 1
11 ft Cable Length PBC2100-11 1
16 ft Cable Length PBC2100-16 1
Special Drop PBC2100-# 1
5 Grommet 36989 1
6 Button Assembly - -
7 Contact Assembly (includes items 6 & 7) 36987 1
8 Gasket 36986 1
* Hardware Kit (includes items 9 thru 16) 36939 1
Not shown Warning Tag 687K3W 1
( # ) Length of Cable in Feet (pushbutton drop).
