Milwaukee M4910-21 - Parts List for Figure E

28
M4910-21
PARTS LIST FOR FIGURE E
KEY PART NO. NUMBER DESCRIPTION QTY.
KEY PART NO. NUMBER DESCRIPTION QTY.
1 039748001117 Air Hose Assembly ................................................... 1 2 039748001116 Hose Assembly ........................................................ 1
3 039748001097 619 Reversible Spray Tip ......................................... 1
4 039748001098 310 Reversible Spray Tip ......................................... 1
5 039748001021 Pistol-Grip Sprayer (Includes Key Nos. 6, 28-30) .... 1 6 039748001099 Spray Gun Filter ....................................................... 1 7 039748001020 High Pressure Fluid Hose (25 ft.) .............................. 1 8 039748001019 Pump Motor Housing ............................................... 1 9 039748004001 Quick Start Label ...................................................... 1 10 039747001090 Barb Hose Fitting ..................................................... 1
11 039747001021 Screw (M5 x 14 mm) ................................................ 8
12 039748001024 Screw (M4 x 6 mm) .................................................. 1
13 039748001022 Ground Washer ........................................................ 1
14 039748001023 Hex Nut .................................................................... 1
15 039748001096 Wavy Washer ............................................................ 3
16 039748001094 Ground Screw .......................................................... 3 17 039748001095 Spring Washer .......................................................... 3 18 039748001025 Screw (M3.9 x 18 mm) ............................................. 4
19 039748004008 Power Switch ........................................................... 1
20 039748004002 Data Label ................................................................ 1 21 039748001032 Screw (M6 x 60 mm) ................................................ 4
22 039748001031 Hex Nut (M6) ............................................................ 4 23 039748001030 Bend Relief ............................................................... 1
24 039748001026 Air Hose (1 ft.) ........................................................... 1 25 039748001028 Air Hose Clamp ........................................................ 2 26 039748001027 Air Hose Connector .................................................. 1 27 039748001034 Air Outlet Cap ........................................................... 1
28 039748004022 Nozzle Sleeve w/Ring ............................................... 1 29 039747001184 Tip Saddle ................................................................ 1
30 039747001185 Tip O-ring ................................................................. 1
