Mimosa Backhaul and B24 Help Content
Mimosa Backhaul Tests
Copyright © 2018 Mimosa Page Page 72
Running a Bandwidth Test
A manual test to assess maximum throughput when minimal or no traffic is present. This test sends 1500-byte
packets using a proprietary UDP-like protocol. Results are shown in corresponding graph on this page. Note that
bandwidth test data is excluded from the Dashboard Performance graph. This is because the test is conducted by
transmitting packets at a low layer between the two radios. Navigating away from this page will stop the test. The
bandwidth test is only available when devices are associated in PTP mode.
Test Duration - The length of the bandwidth test in seconds.
●
Test - Select one of the following options to assess the maximum throughput:
●
Local to Remote - Unidirectional test from the local device to the remote device
●
Remote to Local - Unidirectional test from the remote device to the local device
●
Transmit then Receive - Bidirectional tests conducted one after the other
●
Simultaneous - Bidirectional test conducted at the same time
●
